Location:Index--->Product Center >> Copeland Compressors >> Copeland compressor ZXI14KCE-TFD-647
Name:Copeland compressor ZXI14KCE-TFD-647
Brand:Copeland
Model No.:ZXI14KCE-TFD-647
Country of origional:China
G.W:30KGS/PC
Applications:Medium Temperature

Product Description

Copeland compressor ZXI14KCE-TFD-647

ZX(I) compressors are used within Copeland ZX outdoor refrigeration units for low-temperature applications.

They have been optimized in their design to perfectly fit frozen food application requirements. Thanks to their scroll compliance mechanism, these scroll compressors feature particularly high tolerance to liquid slugging.

Features

High capacity vapor injection technology on ZXI models, for improved efficiency

Optional sound shell allowing up to 10 dBA sound attenuation


Specifications

Applications
Medium Temperature
Compatible Refrigerants
R-404A
R-407A
R-407F
R-448A
R-449A
Cooling Capacity [kW]
8.71
COP
2.65
Displacement [m³/h]
12.7
Enclosure Case
IP 21 (IEC 34)
Frequency [Hz]
50
60
Gross Weight [kg]
30
Harmonized Tariff Schedule (HTS)
8414308189..PCE.16
Height [mm]
418
Length [mm]
242
Low/High Side PS [bar] [g]
28/45
Maximum Operating Current [A]
9.2
Oil Type
POE
PED Category
I
Performances Given At Conditions
-10°C evap. temp.; 45°C cond. temp.; 20 °C suction gas return; 0 K subcooling for R-448A at 50 Hz
Phase
3
Power Input [kW]
3.29
Product Depth/Width [mm]
242
Product Family
Copeland Scroll refrigeration MT
Product Height [mm]
418
Product Length [mm]
242
Single/Tandem
Single
Voltage
380-420 VAC 460 VAC
Voltage@Hz
380-420 V at 50 Hz, 460 V at 60 Hz
Width [mm]
242
