Location:Index--->Product Center >> HVAC Control cools spare parts >> Danfoss Shut-off ball valve, GBC 42s 009L7028
Name:Danfoss Shut-off ball valve, GBC 42s 009L7028
Brand:Danfoss
Model No.:GBC 42s
Part No.:009L7028
Country of origin:China
G.W:2.67kgs/pc
Inlet connection type:Solder, ODF
Outlet connection type:Solder, ODF
Inlet size [in]::1 5/8 in
Outlet size [in]:1 5/8 in

Product Description

Danfoss Shut-off ball valve, GBC 42s  009L7028

General specifications

Characteristic
Value
Gross weight
2.67 Kilogram
Net weight
2.281 Kilogram
Volume
4.312 Liter
Characteristic
Value
EAN/UPC
5702428515733
Proposition 65
Cancer and Reproductive Harm

Product specifications

Characteristic
Value
Access port
No
Approval
C UL US LISTED, CE, EAC
Body material
Brass
CE mark
Yes
China RoHS compliance
Yes with exemptions
Connection material
Copper
Contains batteries
No
Cv value [gal/min]
155.780 gal/min
DG Indicator Profile
Not relevant for dangerous goods
Direction
Straightway
Equipment
Cap w. wire seal
EU RoHS compliance
Yes with exemptions
EU RoHS exemption clause
6(c)
Flow direction
Bi-flow
Flow direction indicator
Embossed 2-way arrow
Fluid Group
2
Ignition source assessment
Yes
Inlet connection type
Solder, ODF
Inlet size [in]
1 5/8 in
Kv value [m³/h]
134.760 m³/h
Material Description
GBC 42s Ball Valve M/4
Max. media temp. Oil free [°C]
80 °C
Max. Working Pressure [bar]
45.0 bar
Max. Working Pressure [psig]
650 psig
Hits: 【Print】
Pre:Saginomiya expansion valve QCX-4734BHSA     Next:Danfoss Shut-off ball valve, GBC 54s 009L7029
